    SGS 1.8 Degree Nema 23 57mm Holding Torque Stepper Motor

    Ask Lasest Price
    Brand Name : Prostepper
    Model Number : PST57H265-4P30
    Certification : CE.ISO.ROHS.SGS
    Price : Negotiable
    Payment Terms : T/T, Western Union, L/C
    Supply Ability : 250000pcs per/ month
    Delivery Time : 7-25 work days
    • Product Details
    • Company Profile

    SGS 1.8 Degree Nema 23 57mm Holding Torque Stepper Motor

    57mm 1.8 degree hybrid stepper motor NEMA23 2 phase stepping motor for packaging machine


    Description of NEMA23 hybrid stepper motor

    1. Accurate position Control

      The angular displacement of the stepping motor can be precise controlled by the number of electrical pulses.Angle accuracy can be controlled within ±0.09°without any feedback devices.

    2. Material quality: The coat is 304 stainless steel, the water jacket is the high compression casting aluminum tube, the red copper coil.

    3. The Fulling product line is sold to major manufacturing Companies for Industry of automation, medical andhealth care equipment, printer machine, packing device,Information Technology,household appliance

      product,AGV and automobile.

    4. .Forward/Reverse Rotation,Pause and Hold

      The forward /reverse rotation of the stepping motor can be controlled by the input sequence of the controlled electric pulses.

      In the case of the a stepping motor lock(the motor winding is energized,there is no external electric pulse command),the stepping motor can still maintain a certain torque output.


    Specifications


    Mode NoPST57H265-4P20

    PST57H265-4P30


    PST57H265-4L40
    Holding Torque1.7N.m
    Related Current2A/Phase3A/Phase4A/Phase
    Resistance2 Ω/Phase0.9Ω /Phase0.5Ω/Phase
    Inductance6MH/Phase2.7MH/Phase1.6MH/Phase
    Inertia280g.cm2
    Weight0.72kgs
    Length55.5mm
    ConnectionP

    Mode NoPST57H276-4P30

    PST57H276-4L40


    PST57H276-4L50
    Holding Torque2N.m
    Related Current3A/Phase4A/Phase5A/Phase
    Resistance1.1Ω/Phase0.65Ω /Phase0.37Ω/Phase
    Inductance4.2MH/Phase2.35MH/Phase1.8MH/Phase
    Inertia480g.cm2
    Weight1.1kgs
    Length76.5mm
    ConnectionPL




    • Stepping Accuracy: ± 5%
    • Resistance Accuracy: ± 10%
    • Inductance Accuracy: ± 20%
    • Temperature Rise: 80°C Max.
    • Ambient Temperature: -20°C ... +50°C
    • Insulation Resistance: 100MOhm min. 500V DC
    • Withstand: 500V AC, 1 Minute


    Stepper motors are diverse in their uses, but some of the most common include:


    Applications of 1.8 degree Stepper Motor

    • 3D printing equipment
    • Textile machines
    • Printing presses
    • Gaming machines
    • Medical imaging machinery
    • Small robotics
    • CNC milling machines
    • Welding equipment

    Features:

    • high precision
    • high torque
    • durable
    • medium size

    Note

    The winding on this article is a 4 Wire Bipolar.

    0.9° and 1.8° Hybrid Stepper Motors

    1.8° Step Angle,The motors are directly compatible with the stepper motor drive boards and also drive either motor (if required) in the half step mode i.e. 0.9° per step resulting in higher resolution, greater performance stability and faster stepping rates. Direction, velocity, acceleration/deceleration can be controlled by a stepper motor controller.,Applying the correct electrical pulse sequence to the windings of the stepper motor results in a 1.8° step angle rotation of the spindle (i.e. 200 steps per revolution). When correctly loaded and driven these motors will produce discrete output steps. The number of steps and speed of rotation are determined by the number of pulses and frequency of the input signal. This provides an ideal method for speed and position control. The motors are directly compatible with stepper motor drive boards.
