1.8 degree 60mm Stepping Motor Brake Stepper Motor With Encoder nema24 For medical system

• Product description of 2 phase hybrid brake stepper motor

• Automatic assembly line, improve production efficiency, low cost without human operation, one line down intelligent mechanical automatic assembly

• The Fulling product line is sold to major manufacturing Companies for Industry of automation, medical andhealth care equipment, printer machine, packing device,Information Technology,household appliance,product,AGV and automobile.

• Online testing of technical parameters to ensure the consistency of data product parameters
• Material quality: The coat is 304 stainless steel, the water jacket is the high compression casting aluminum tube, the red copper coil.
• Electromagnetic furnace optimization design, lift torque, reduce temperature rise, so that the motor running smoothly

• Accurate position Control

  The angular displacement of the stepping motor can be precise controlled by the number of electrical pulses.Angle accuracy can be controlled within ±0.09°without any feedback devices.

• Specifications

• Speed/Torque Characteristics(Reference Value)

Encoder Specifications Brake Specifications

• Stepping Accuracy: ± 5%
• Resistance Accuracy: ± 10%
• Inductance Accuracy: ± 20%
• Temperature Rise: 80°C Max.
• Ambient Temperature: -20°C ... +50°C
• Insulation Resistance: 100MOhm min. 500V DC
• Withstand: 500V AC, 1 Minute

Lower heat Low noise &smooth

The design of prostepper' motor Improved manufacturing processes

selected with new materials gets a lower enable all components of

resistance value when compared with prostepper' stepper motors to

motors of the same thickness and the achieve better matching precision

same torque, this makes a greater degree and more stable internal

of improvement for the thermal structures. This reduces vibration

conductivity performance of the motor, and noise effectively when the

thus greatly reduces the temperature motor operates, which makes

rise of the motor. prostepper' stepper motors stand

out by providing quieter and

smoother operation.

• Primary Competitive Advantages:

· Green Product

· Military Specifications

· Packaging

· Price

· Product Features

· Product Performance

· Prompt Delivery

· Quality Approvals

· Service

· Small Orders Accepted

· Brand-name Parts

· Origin

· Experienced Staff

• Quality assurance:

1. All stepper motors have CE and RoHS certification
2. All motors are tested by a toasting machine for 72 hours
3. All the motors will be shipped after testing

• Tips: How to overcome the vibration and noises of 2-phase hybrid stepper motor when rotating at low velocity?
• The vibration and noise of the stepper motor rotating at low velocity its the intrinsic defects, which can be generally overcome by adopting following schemes:
• If the stepper motor works at resonance region, the resonance region can be evaded by changing mechanical transmissions such as velocity ratio.
• Use subdivided driver, which is the most common and simple method.
• Replace for the stepper motor with smaller stepping angle, like 3-phase or 5-phase stepper motor.
• Replace for AC servo motor, which can nearly overcome vibration and noise, but the cost is quite high.
• Add magnetic damper to the shaft of motor, such product has been available in the market, but the mechanical structure is changed a lot.

CHANGZHOU PROSTEPPER CO.,LTD. is a manufacturer of stepping motors with well-equipped testing equipment and strong technical force. we have got ISO9001,ROHS and CE certificate, we are specializing in researching, developing and serve stepper motor in Changzhou,China. We supply the production of each type of stepper motor, such as hybrid stepper motor, Encoder type Hybrid Stepper motor, gear box type motor, we accept OEM and ODM orders. Our products are widely used in Dispensing machine, hot stamping machine, manipulator, robot, repair table, labeling machine, laser cutting machine, SMT equipment, medical equipment, Printing machine, textile machinery, packaging machinery, CNC machine tools, robots and other automation control field. We have rich experience in the development of design experts and technical staff .

With advanced stepper motor production equipment and production line, quality management systems and test equipment. The products are mainly used in various type of automatic precision control equipment such as stage lighting, absorbing the essence of motor manufacturing, so that the quality of products is continuously improved and the enterprise is constantly developing. Prostepper motor insists on using stable quality and creating a good reputation to realize prostepper’s commitment to customers.

Prostepper motor has a strong, much experience, pragmatic and innovative production team. Based on high-quality products, we adhere to the customer oriented service concept.

Creat the best cost effective solution and adhere to the “ People-orientedintroduction optimization, the purpose of “ Stable quality and moving customers” is to serve new and old customers.

Welcome all the friends from all walks of life to visit, guide and negotiate business.
