35mm 1.8 degree stepper motor 2 phase hybrid NEMA14 Encoder stepper motor for home appliances

Product description of encoder stepper motor

1. Strictly control the production of parts to improve the quality of parts

   Stepping motor is a mechanical structure,which does not need be changed by electric brush or Hall sensor,thus reducing the probability and increasing the motor life.Stepping motor life usually determined by the life of the bearing.

2. .Accurate Speed Control

   The rotational speed of the stepping motor can be precisely controlled ,By controlling the frequency of the electric pulse.

3. Fulling product line is sold to major manufacturing Companies for Industry of automation, medical andhealth care equipment, printer machine, packing device,Information Technology,household appliance,product,AGV and automobile.

4. Online testing of technical parameters to ensure the consistency of data product parameters

5. Accurate position Control

   The angular displacement of the stepping motor can be precise controlled by the number of electrical pulses.Angle accuracy can be controlled within ±0.09°without any feedback devices.




Encoder stepper motor of Specifications

• 1. Shaft Dia= 5mm
• 2. Step Angle: 1.8
• 3. Phase Current 1.2A
• 4. Phase Resistance: 1 .5Ohm
• 5. Phase Inductance: 2.8mH
• 6. Holding Torque: 40N.cm
• 7. Braking Torque: 2.2N.cm
• 8. Rotor Inertia: 54g.cm32;
• 9. Wire: 4(Blue, green, black, red)
• 10. Max. Temperature Rise: 80"C (rated current, 2 phase on)11. Operating Temperature: -20*C-+70"C
• 11. Insulation Resistance: 100 MQ Min., 500VDC
• 12. Radial Clearance: 0.02Max, (450g-Load)
• 13. Axial Clearance: 0.08Max. (450g-Load)

Quality assurance:

• 1. All stepper motors have CE and RoHS certification
• 2. All motors are tested by a toasting machine for 72 hours
• 3. All the motors will be shipped after testing

Encoder stepper motor Application

Stepper motors are diverse in their uses, but some of the most common include:

• 3D printing equipment
• Textile machines
• Printing presses
• Gaming machines
• Medical imaging machinery
• Small robotics
• CNC milling machines
• Welding equipment

Primary Competitive Advantages:

• Green Product
• Military Specifications
• Packaging
• Price
• Product Features
• Product Performance
• Prompt Delivery
• Quality Approvals
• Service
• Small Orders Accepted
• Brand-name Parts
• Origin
• Experienced Staff

​Tips: What is stepper motor?

• Stepper motor is an actuator transforming electric pulse into angular displacement. Popularly, when receiving a pulse signal, the stepper motor will rotate a fixed angle (namely ''stepping angle'') according to the direction set for the stepper motor. The angular displacement volume can be controlled by controlling the pulse number to achieve the purpose of positioning accurately. In the meantime, the rotational velocity and acceleration of motor can be controlled by controlling the pulse frequency to achieve the purpose of speed control.

CHANGZHOU PROSTEPPER CO.,LTD. is a manufacturer of stepping motors with well-equipped testing equipment and strong technical force. we have got ISO9001,ROHS and CE certificate, we are specializing in researching, developing and serve stepper motor in Changzhou,China. We supply the production of each type of stepper motor, such as hybrid stepper motor, Encoder type Hybrid Stepper motor, gear box type motor, we accept OEM and ODM orders. Our products are widely used in Dispensing machine, hot stamping machine, manipulator, robot, repair table, labeling machine, laser cutting machine, SMT equipment, medical equipment, Printing machine, textile machinery, packaging machinery, CNC machine tools, robots and other automation control field. We have rich experience in the development of design experts and technical staff .

With advanced stepper motor production equipment and production line, quality management systems and test equipment. The products are mainly used in various type of automatic precision control equipment such as stage lighting, absorbing the essence of motor manufacturing, so that the quality of products is continuously improved and the enterprise is constantly developing. Prostepper motor insists on using stable quality and creating a good reputation to realize prostepper’s commitment to customers.

Prostepper motor has a strong, much experience, pragmatic and innovative production team. Based on high-quality products, we adhere to the customer oriented service concept.

Creat the best cost effective solution and adhere to the “ People-orientedintroduction optimization, the purpose of “ Stable quality and moving customers” is to serve new and old customers.

Welcome all the friends from all walks of life to visit, guide and negotiate business.
