Nema23 1.8 degree Gear Stepper Motor 57mm Bi-polar Stepping Motor
for automative equipment
Changzhou Prostepper Co. Ltd is a manufacturer and exporter of
various of stepper motors with 20 years experience.
NEMA 8,11,14,17,23,24, 34, 42, 52 Stepper Motor & Driver with CE,
RoHS, OEM 2 phase stepper motor, stepping motor, step motor
Professional manfacuturer for stepper motor, have NEMA8, NEMA11.
NEMA14, NEMA17, NEMA23, NEMA34
1.8 degree, 0.9 degree. Single shaft and double shaft
The Torque pulse rate Characteristics of a Stepper Motor gives the variation of an electromagnetic torque as a function of
stepping rate in pulse per second (PPS). There are two
characteristic curves 1 and 2 shown in the figure below. Curve one
is denoted by a blue colour line is known as the Pull-in torque. It shows the maximum stepping rate for the various values of the
load torque at which the motor can start, synchronise, stop or
reverse.
Specifications
| Specifications |
| type | Planetary |
| Housing material | Metal |
| No-load Backlash | <25arcmin |
| Bearing at output | Ball Bearing |
| Operating temperature range | -30°C~+80°C |
| Reduction Stage | Reduction Ratio | Ultimate Torque N.m | Efficiency | L2mm |
| 1 | 3 | 25 | 95% | 53 |
| 4 |
| 5 |
| 10 |
| 2 | 15 | 45 | 90% | 70 |
| 20 |
| 30 |
| 40 |
| 50 |
Product description of Gear Box stepper motor
1.The material is selected from well-known manufacturers at home
and abroad. The advantages are light weight, good heat dissipation
performance, good thermal conductivity, die-casting, good
plasticity, higher elongation than iron, low noise, good motion
stability, the disadvantages are high price, low hardness.
2.The Fulling product line is sold to major manufacturing Companies
for Industry of automation, medical andhealth care equipment,
printer machine, packing device,Information Technology,household
appliance product,AGV and automobile.
3.Online testing of technical parameters to ensure the consistency
of data product parameters
4.Longer Life
Stepping motor is a mechanical structure,which does not need be
changed by electric brush or Hall sensor,thus reducing the
probability and increasing the motor life.Stepping motor life
usually determined by the life of the bearing.
Quality control process:
Raw material inspection
Inspecting according to the standard of testing raw material or the
drawing
Monitoring and measurement in production process
Self checking-tested by QC-Batches production
Final checking and make experiment
All products should be through testing by the professional
equipment
Advantages of Hybrid Stepper Motor
The advantages of the Hybrid Stepper Motor are as follows:-
- The length of the step is smaller.
- It has greater torque.
- Provides Detent Torque with the de-energized windings.
- Higher efficiency at lower speed.
- Lower stepping rate.
