20mm 2 phase hybrid NEMA8 bipolar stepper motor1.8 step motor

Product description

• Input pulse decides the rotation angle of the motor.
• High accuracy of around 3 to 5% a step.
• Provides good starting, stopping and reversing.
• Control of this motor is less costly because of exclusion of complex control circuitry.
• The speed is proportional to the frequency of the input pulses.

Specifications

Mode No:PEM20H228E1KzS

Mode No:PEM20H228E2KzS

Quality control process:

• Incoming inspection: The inspection shall be conducted according to the Requirements of the Incoming Inspection Specification or the product drawing
• Monitoring and measurement of production process (self-inspection - inspection - batch production)
• Final inspection and test
• All inspectors must be trained and then put on duty
• Nonconforming products shall be executed in accordance with Nonconforming Product Control Procedures
• Raw material inspection
• Inspecting according to the standard of testing raw material or the drawing
• Monitoring and measurement in production process
• Self checking-tested by QC-Batches production
• Final checking and make experiment
• All products should be through testing by the professional equipment
• Stepping Accuracy: ± 5%
• Resistance Accuracy: ± 10%
• Inductance Accuracy: ± 20%
• Temperature Rise: 80°C Max.
• Ambient Temperature: -20°C ... +50°C
• Insulation Resistance: 100MOhm min. 500V DC
• Withstand: 500V AC, 1 Minute

  ---

Working principle of stepper motor

To make the motor shaft turn, first one electromagnet is given power, which makes the gear’s teeth magnetically attracted to the electromagnet’s teeth. The point when the gear’s teeth are thus aligned to the first electromagnet, they are slightly offset from the next electromagnet. So when the next electromagnet is turned ON and the first is turned OFF, the gear rotates slightly to align with the next one and from there the process is repeated. Each of those slight rotations is called a step, with an integer number of steps making a full rotation. In that way, the motor can be turned by a precise. Stepper motor doesn’t rotate continuously, they rotate in steps. There are 4 coils with a 90o angle between each other fixed on the stator. The stepper motor connections are determined by the way the coils are interconnected. In a stepper motor, the coils are not connected. The motor has a 90o rotation step with the coils being energized in a cyclic order, determining the shaft rotation direction. The working of this motor is shown by operating the switch. The coils are activated in series in 1-sec intervals. The shaft rotates 90o each time the next coil is activated. Its low-speed torque will vary directly with current.

Buyer's Concerns

Q1: What about your warranty?

A: We guarantee is one year for sea order .

Q2: Do you have any certificates?

A: Yes, we have. All the motors have been approved by CE and RoHS.

Q3: Do you offer OEM AND ODM service?

A: Yes. We can supply OEM and make customized design for any specific application.

CHANGZHOU PROSTEPPER CO.,LTD. is a manufacturer of stepping motors with well-equipped testing equipment and strong technical force. we have got ISO9001,ROHS and CE certificate, we are specializing in researching, developing and serve stepper motor in Changzhou,China. We supply the production of each type of stepper motor, such as hybrid stepper motor, Encoder type Hybrid Stepper motor, gear box type motor, we accept OEM and ODM orders. Our products are widely used in Dispensing machine, hot stamping machine, manipulator, robot, repair table, labeling machine, laser cutting machine, SMT equipment, medical equipment, Printing machine, textile machinery, packaging machinery, CNC machine tools, robots and other automation control field. We have rich experience in the development of design experts and technical staff .

With advanced stepper motor production equipment and production line, quality management systems and test equipment. The products are mainly used in various type of automatic precision control equipment such as stage lighting, absorbing the essence of motor manufacturing, so that the quality of products is continuously improved and the enterprise is constantly developing. Prostepper motor insists on using stable quality and creating a good reputation to realize prostepper’s commitment to customers.

Prostepper motor has a strong, much experience, pragmatic and innovative production team. Based on high-quality products, we adhere to the customer oriented service concept.

Creat the best cost effective solution and adhere to the “ People-orientedintroduction optimization, the purpose of “ Stable quality and moving customers” is to serve new and old customers.

Welcome all the friends from all walks of life to visit, guide and negotiate business.
